Durable PLC Programmable Logic Controller Mitsubishi Module AJ65SBTB1 32T

Ask Lasest Price
Brand Name :	Mitsubishi
Model Number :	AJ65SBTB1-32T
Certification :	CO
Price :	Negotiable
Payment Terms :	Western Union, T/T, L/C,Paypal
Supply Ability :	1000pcs/Day
Delivery Time :	0-2 days

Add to Cart

Product Details
Company Profile

Durable PLC Programmable Logic Controller Mitsubishi Module AJ65SBTB1 32T

Mitsubishi Module AJ65SBTB1-32T PLC Programmable Logic Controller

AJ65SBTB1-32T

Product Technical Data

No. of outputs:	32
Isolation method:	Photocoupler
No. of occupied stations:	1 station 32 points assignment (use 32 points)
I/O module power supply:
Voltage:	20.4 to 26.4V d.c. (ripple ratio: within 5%)
Current:	65mA or lower (when 24V d.c., all points ON)
Network speed:	Up to 10Mbps
Network distance:	Up to 1.2km
Surge suppressor:	Zener diode
Protection function:	Overload protection function
	Overvoltage protection
	Function and overheat protection function
Response time:
OFF—ON:	0.5ms or lower
ON—OFF:	1.5ms or lower (resistive load)
External power supply for output part:
Voltage:	10.2 to 26.4V d.c. (ripple ratio: within 5%)
Current:	50mA or lower (TYP. 24V dc./common)
	Not including external load current
Wiring method for common:	32 points/common
Rated load voltage:	12/24V d.c.
Operating load voltage range:	10.2 to 26.4V d.c. (ripple ratio: within 5%)
Max. load current:	0.5A/point, 4.8A/common
Max. inrush current:	1.0A, 10ms or lower
Leakage current at OFF:	0.25mA or lower
Max. voltage drop at ON:	0.3V or lower (TYP.) 0.5A, 0.6V or lower (MAX.) 0.5A
Output format:	Sink type

Product Feature

1. Up to 64 I/O modules with a maximum of 32 inputs or 32 outputs each can be connected
2. Compact design which is tough and highly shock-resistant
3. Modules can be put in a horizontal arrangement or one of four orientation on a flat surface.
4. DIN rail or screw mounting
