| range | TeSys |
| product name | TeSys D |
| product or component type | Contactor |
| device short name | LC1D |
| [Ue] rated operational voltage | <= 300 V DC for power circuit |
| <= 690 V AC 25...400 Hz for power circuit |
| contactor application | Motor control |
| Resistive load |
| utilisation category | AC-1 |
| AC-3 |
| AC-4 |
| poles description | 3P |
| power pole contact composition | 3 NO |
| [Ie] rated operational current | 40 A (<= 60 °C) at <= 440 V AC AC-3 for power circuit |
| 60 A (<= 60 °C) at <= 440 V AC AC-1 for power circuit |
| motor power kW | 18.5 kW at 380...400 V AC 50/60 Hz AC-3 |
| 22 kW at 500 V AC 50/60 Hz AC-3 |
| 30 kW at 660...690 V AC 50/60 Hz AC-3 |
| 11 kW at 220...230 V AC 50/60 Hz AC-3 |
| 9 kW at 400 V AC 50/60 Hz AC-4 |
| 22 kW at 415...440 V AC 50/60 Hz AC-3 |
| motor power HP (UL / CSA) | 5 hp at 230/240 V AC 50/60 Hz for 1 phase motors |
| 10 hp at 230/240 V AC 50/60 Hz for 3 phases motors |
| 30 hp at 575/600 V AC 50/60 Hz for 3 phases motors |
| 3 hp at 115 V AC 50/60 Hz for 1 phase motors |
| 10 hp at 200/208 V AC 50/60 Hz for 3 phases motors |
| 30 hp at 460/480 V AC 50/60 Hz for 3 phases motors |
| control circuit type | AC 50/60 Hz |
| [Uc] control circuit voltage | 220 V AC 50/60 Hz |
| auxiliary contact composition | 1 NO + 1 NC |
| [Uimp] rated impulse withstand voltage | Conforming to IEC 60947 |
| overvoltage category | III |
| [Ith] conventional free air thermal current | 60 A at <= 60 °C for power circuit |
| 10 A at <= 60 °C for signalling circuit |
| Irms rated making capacity | 800 A at 440 V for power circuit conforming to IEC 60947 |
| 140 A AC for signalling circuit conforming to IEC 60947-5-1 |
| 250 A DC for signalling circuit conforming to IEC 60947-5-1 |
| rated breaking capacity | 800 A at 440 V for power circuit conforming to IEC 60947 |
